    High Capacity V Bank H13 500Pa High Efficiency Air Filter black

    Ask Lasest Price
    Brand Name : SGAIR
    Model Number : FLOMAX
    Certification : CE
    Price : Consulting customer service
    Payment Terms : T/T
    Supply Ability : Consulting customer service
    Delivery Time : Consulting customer service
    • Product Details
    • Company Profile

    High Capacity V Bank H13 500Pa High Efficiency Air Filter black

    High Capacity V Bank Hepa Air Filter With Longer Service Life​


    Applications:


    The FlowMax V2000 HEPA Filter is designed to meet the demanding airflow and efficiency requirements of the most critical applications.


    Multipie mini-pleat media packs, assembled into a series of V-banks, permit substatially more media to be contained in the filter - double the media typically found in most HEPA Filters. Maxinum effective media area provides greater airflow capacity, low resistance, high dust holding capacity, and unusually long service life.


    The V-bank configuration provides greater airflow capacity and longer service life, while lowering operating costs.


    Advantages:


    Low energy comsumption and lower operating costs.


    Ideal for demanding operating conditions in critical applications.


    Longer service life - 398 square feet of media - means fewer changeouts.


    High capacity operation with minimum resistance to airflow. 2000 CFM rated airflow at 0.88 in.w.g.


    Chemical-resistant ABS frame provides superior strength.


    Typical Applications:


    FlowMax HEPA filters are ideal for applications operating with higher airflows, up to 600 FPM, and requiring ultra low pressure drop.


    • Semiconductor and electronics manufacturing
    • Pharmaceutical processing
    • Photo film manufacturing / processing
    • Hospitals, laboratories, and optical facilities
    • Food processing



    Materials and Working Conditions:

    • Media: Polypropylene or glass fibre paper
    • Separator:Hot-melt beads
    • Frame: GI;Plastic
    • Efficiency range from F9 ,H10,H11,H13(EN 1822)
    • Initial resistance: 160 Pa @ 3400 m3/h
    • Recommended final pressure drop : 400-500Pa
    • Humidity resistance: 100%
    • Max Temperature: 80 ℃
    • Sealant: Polyurethane rubber PU
    • DIN 53438 Flammability: F1
    • UL 900 Standard : Class 2
    • Max.air flow rate: 125% of rated air flow
    • Gasket: one piece half round continuous gasket
    • Available in Box or Single flange type.


    Specifications:

    Size(WxHxD)mmFilter EfficiencyMedia area m3Airflow/pressure drop m3/h/Pa
    305x610x292E10142000/160
    595x595x292E10214000/160
    610x610x292E10355000/160
    305x610x292E12161500/110
    595x595x292E12333400/110
    610x610x292E12404000/110
    289x595x292H13161300/110
    595x595x292H13383200/110
    610x610x292H13404000/110

    Other sizes is available!
